Printing Technology: FDM, Accuracy on the X-axis, Y: 40 microns, Z axis accuracy: 10 microns Materials: PLA, ABS, HIPS, PVA, FLEX, Nylon, PC, PP, PETG, Wood, SBS, POM, min. layer thickness: 50 microns Desktop: 210 x 170 mm, table material: glass, heating the table Design: extruders: 2, Extruder temperature: 285 degC
General Characteristics |
|
Printing Technology |
FDM |
Number of extruders |
2 |
Corpus |
open-ended |
Frame material |
steel |
Min. layer thickness |
50 microns |
Printable material |
PLA, ABS, HIPS, PVA, FLEX, Nylon, PC, PP, PETG, Wood, SBS, POM |
Material Thickness |
1.75 mm |
Power Utilized |
350 W |
Colors |
Red (disambiguation) |
Technical Specifications |
|
Positioning accuracy of the axis X, Y |
40 microns |
Positioning accuracy of the axis Z |
10 micron |
Extruder temperature |
285 °C |
Max. printing speed |
300 mm/s |
Color Prints |
|
Displays |
|
MANAGEMENT |
Button |
Interfaces |
USB, microSD/SD card |
File formats supported |
.stl |
Cameras |
|
Work Desk |
|
Length of printing area |
210 mm |
Wideness of the printing area |
170 mm |
Height of the printing area |
170 mm |
Table material |
Glass |
Warm the table |
|
Temperature of the table |
125 °C |
Components |
|
Memory Cards |
|
Nozzle |
0.3 mm |
Requires assemblies |
|
Dimensions and weight |
|
Length |
320 mm |
Width |
390 mm |
Heights |
375 mm |
Weight (disambiguation) |
12 kgs |
