Printing Technology: FDM, Accuracy on the X-axis, Y: 11 microns, Z axis accuracy: 2.5 microns Materials: PLA, ABS, PC, PETG, Nylon (PA), Carbon, min. layer thickness: 50 microns Desktop: 1000x1020 x1030 mm, heating the table Design: extruders: 2, Extruder temperature: 420 degC
General Characteristics |
|
Printing Technology |
FDM |
Number of extruders |
2 |
Corpus |
closed-ended |
Min. layer thickness |
50 microns |
Printable material |
PLA, ABS, PC, PETG, Nylon (PA), Carbon |
Material Thickness |
1.75 mm |
Power Utilized |
4,500 W |
Colors |
Grey |
Technical Specifications |
|
Positioning accuracy of the axis X, Y |
11 microns |
Positioning accuracy of the axis Z |
2.5 microns |
Extruder temperature |
420 °C |
Max. printing speed |
120 mm/s |
Color Prints |
|
Displays |
|
MANAGEMENT |
touchscreen display, mobile app |
Interfaces |
USB, Wi-Fi |
File formats supported |
.gcode, .stl, .amf, .obj |
Thread end detection sensor |
|
Work Desk |
|
Length of printing area |
1,000 mm |
Wideness of the printing area |
1,000 mm |
Height of the printing area |
1,000 mm |
Warm the table |
|
Temperature of the table |
100 °C |
Automated platform calibration |
|
Components |
|
Nozzle |
1 mm |
Requires assemblies |
|
Dimensions and weight |
|
Length |
1 810 mm |
Width |
1,350 mm |
Heights |
1 920 mm |
Weight (disambiguation) |
650 kg |
