Printing Technology: FDM, Accuracy on the X-axis, Y: 12.5 microns, Z axis accuracy: 1 micron Materials: PLA, ABS, HIPS, PETG, min. layer thickness: 20 microns Desktop: 175 x 180 mm, table material: glass, heating the table Design: extruders: 1, Extruder temperature: 260 degC
General Characteristics |
|
Printing Technology |
FDM |
Number of extruders |
1 |
Corpus |
closed-ended |
Min. layer thickness |
20 microns |
Printable material |
PLA, ABS, HIPS, PETG |
Material Thickness |
1.75 mm |
Power Utilized |
180 W |
Colors |
White |
Technical Specifications |
|
Positioning accuracy of the axis X, Y |
12.5 microns |
Positioning accuracy of the axis Z |
1 micron |
Extruder temperature |
260 °C |
Color Prints |
|
Displays |
|
MANAGEMENT |
Button |
Interfaces |
USB, microSD/SD card, Wi-Fi |
File formats supported |
.stl, .amf, .obj, .3w, .3mf, .ply, .igs, .stp |
Cameras |
|
Pauses in printing |
|
Work Desk |
|
Length of printing area |
175 mm |
Wideness of the printing area |
175 mm |
Height of the printing area |
175 mm |
Table material |
Glass |
Warm the table |
|
Automated platform calibration |
|
Components |
|
Memory Cards |
|
Nozzle |
0.4 mm |
Requires assemblies |
|
Dimensions and weight |
|
Length |
430 mm |
Width |
420 mm |
Heights |
380 mm |
Weight (disambiguation) |
13 kg (disambiguation) |
