Printing Technology: FDM, Accuracy on the X-axis, Y: 6 microns, Z axis accuracy: 0.4 microns Materials: PLA, ABS, HIPS, Nylon, PET, PP, min. layer thickness: 20 microns Desktop: 255 x 190 mm, table material: ceramics, heating the table Design: extruders: 2, Extruder temperature: 270 degC
General Characteristics |
|
Printing Technology |
FDM |
Number of extruders |
2 |
Corpus |
closed-ended |
Frame material |
steel |
Min. layer thickness |
20 microns |
Printable material |
PLA, ABS, HIPS, Nylon, PET, PP |
Material Thickness |
1.75 mm |
Power Utilized |
600 W |
Colors |
White |
Technical Specifications |
|
Positioning accuracy of the axis X, Y |
6 micron |
Positioning accuracy of the axis Z |
0.4 microns |
Extruder temperature |
270 °C |
Displays |
|
MANAGEMENT |
touchscreen display |
Interfaces |
USB, microSD/SD card |
File formats supported |
.stl, .obj, .3mf, .jpg |
Cameras |
|
Pauses in printing |
|
Control of residual plasticity |
|
Thread end detection sensor |
|
Work Desk |
|
Length of printing area |
255 mm |
Wideness of the printing area |
190 mm |
Height of the printing area |
195 mm |
Table material |
Ceramics |
Warm the table |
|
Temperature of the table |
160 °C |
Automated platform calibration |
|
Components |
|
Nozzle |
0.4 mm |
Requires assemblies |
|
Dimensions and weight |
|
Length |
564 mm |
Width |
635 mm |
Heights |
563 mm |
Weight (disambiguation) |
26 kg (disambiguation) |
