Printing Technology: FDM, Accuracy on the X-axis, Y: 100 microns, Z axis accuracy: 100 microns Materials: PLA, ABS, PETG, TPU, Wood, min. layer thickness: 10 microns Desktop: 300 x 340 mm, table material: glass Design: extruders: 1
General Characteristics |
|
Printing Technology |
FDM |
Number of extruders |
1 |
Corpus |
open-ended |
Frame material |
Aluminium |
Min. layer thickness |
10 micron |
Printable material |
PLA, ABS, PETG, TPU, Wood |
Material Thickness |
1.75 mm |
Power Utilized |
350 W |
Colors |
black |
Technical Specifications |
|
Positioning accuracy of the axis X, Y |
100 microns |
Positioning accuracy of the axis Z |
100 microns |
Max. printing speed |
180 mm/s |
Color Prints |
|
Displays |
|
MANAGEMENT |
joystick |
Interfaces |
USB, microSD/SD card |
File formats supported |
.stl, .amf, .obj |
Cameras |
|
Pauses in printing |
|
Thread end detection sensor |
|
Work Desk |
|
Length of printing area |
300 mm |
Wideness of the printing area |
300 mm |
Height of the printing area |
340 mm |
Table material |
Glass |
Warm the table |
|
Temperature of the table |
110 °C |
Components |
|
Memory Cards |
|
Nozzle |
0.4 mm |
Requires assemblies |
|
Dimensions and weight |
|
Length |
513 mm |
Width |
563 mm |
Heights |
590 mm |
Weight (disambiguation) |
9.5 kg |
