Printing Technology: FDM, Accuracy on the X-axis, Y: 100 microns, Z axis accuracy: 100 microns Materials: PLA, PETG, TPU, min. layer thickness: 100 microns Desktop: 220 x 250 mm, table material: glass, heating the table Design: extruders: 1
General Characteristics |
|
Printing Technology |
FDM |
Number of extruders |
1 |
Corpus |
open-ended |
Frame material |
Aluminium |
Min. layer thickness |
100 microns |
Printable material |
PLA, PETG, TPU |
Material Thickness |
1.75 mm |
Colors |
black |
Technical Specifications |
|
Positioning accuracy of the axis X, Y |
100 microns |
Positioning accuracy of the axis Z |
100 microns |
Color Prints |
|
Displays |
|
MANAGEMENT |
joystick |
Interfaces |
USB, microSD/SD card |
Cameras |
|
Pauses in printing |
|
Work Desk |
|
Length of printing area |
220 mm |
Wideness of the printing area |
220 mm |
Height of the printing area |
250 mm |
Table material |
Glass |
Warm the table |
|
Temperature of the table |
100 °C |
Automated platform calibration |
|
Components |
|
Nozzle |
0.4 mm |
Requires assemblies |
|
Dimensions and weight |
|
Length |
475 mm |
Width |
470 mm |
Heights |
620 mm |
Weight (disambiguation) |
7.8 kg |
