Printing Technology: FDM, Accuracy on the X-axis, Y: 100 microns, Z axis accuracy: 100 microns Materials: PLA, ABS, HIPS, FLEX, TPU Desktop: 220 x 250 mm, table material: aluminium, heating the table Design: extruders: 1, Extruder temperature: 255 degC
General Characteristics |
|
Printing Technology |
FDM |
Number of extruders |
1 |
Corpus |
open-ended |
Frame material |
Aluminium |
Printable material |
PLA, ABS, HIPS, FLEX, TPU |
Material Thickness |
1.75 mm |
Power Utilized |
360 W |
Colors |
black |
Technical Specifications |
|
Positioning accuracy of the axis X, Y |
100 microns |
Positioning accuracy of the axis Z |
100 microns |
Extruder temperature |
255 °C |
Max. printing speed |
180 mm/s |
Color Prints |
|
Displays |
|
MANAGEMENT |
Button |
Interfaces |
USB, microSD/SD card |
File formats supported |
.stl, .amf, .obj |
Cameras |
|
Pauses in printing |
|
Work Desk |
|
Length of printing area |
220 mm |
Wideness of the printing area |
220 mm |
Height of the printing area |
250 mm |
Table material |
Aluminium |
Warm the table |
|
Temperature of the table |
110 °C |
Automated platform calibration |
|
Components |
|
Nozzle |
0.4 mm |
Requires assemblies |
|
Dimensions and weight |
|
Length |
440 mm |
Width |
410 mm |
Heights |
465 mm |
Weight (disambiguation) |
8 kg (disambiguation) |
