Printing Technology: FDM, Accuracy on the X-axis, Y: 12.7 microns, Z axis accuracy: 1.25 microns Materials: PLA, ABS, HIPS, PVA, FLEX, Nylon, PC, PP, PETG, TPU, PEEK, min. layer thickness: 20 microns Desktop: 400 x 300 mm, table material: glass, heating the table Design: extruders: 2, Extruder temperature: 420 degC
General Characteristics |
|
Printing Technology |
FDM |
Number of extruders |
2 |
Corpus |
closed-ended |
Frame material |
steel |
Min. layer thickness |
20 microns |
Printable material |
PLA, ABS, HIPS, PVA, FLEX, Nylon, PC, PP, PETG, TPU, PEEK |
Material Thickness |
1.75 mm |
Power Utilized |
1,500 W |
Colors |
grey, blue |
Technical Specifications |
|
Positioning accuracy of the axis X, Y |
12.7 microns |
Positioning accuracy of the axis Z |
1.25 microns |
Extruder temperature |
420 °C |
Max. printing speed |
180 mm/s |
Color Prints |
|
Displays |
|
MANAGEMENT |
touchscreen display |
Interfaces |
USB |
File formats supported |
.gcode, .stl, .amf, .obj |
Pauses in printing |
|
Thread end detection sensor |
|
Work Desk |
|
Length of printing area |
400 mm |
Wideness of the printing area |
300 mm |
Height of the printing area |
300 mm |
Table material |
Glass |
Warm the table |
|
Temperature of the table |
120 °C |
Automated platform calibration |
|
Components |
|
Memory Cards |
|
Nozzle |
0.4 mm |
Requires assemblies |
|
Dimensions and weight |
|
Length |
620 mm |
Width |
485 mm |
Heights |
680 mm |
Weight (disambiguation) |
48 kg (disambiguation) |
