Printing Technology: FDM, Accuracy on the X-axis, Y: 15.6 microns, Z axis accuracy: 1.56 microns Materials: PLA, ABS, HIPS, PVA, Nylon, PC, PETG, PEEK, PEKK, PPSU, min. layer thickness: 50 microns Desktop: 305 x 406 mm, table material: ceramics, heating the table Design: extruders: 2, Extruder temperature: 500 degC
General Characteristics |
|
Printing Technology |
FDM |
Number of extruders |
2 |
Corpus |
closed-ended |
Min. layer thickness |
50 microns |
Printable material |
PLA, ABS, HIPS, PVA, Nylon, PC, PETG, PEEK, PEKK, PPSU |
Material Thickness |
1.75 mm |
Power Utilized |
3,000 W |
Colors |
black, blue |
Technical Specifications |
|
Positioning accuracy of the axis X, Y |
15.6 microns |
Positioning accuracy of the axis Z |
1.56 microns |
Extruder temperature |
500 °C |
Max. printing speed |
500 mm/s |
Color Prints |
|
Displays |
|
MANAGEMENT |
touchscreen display |
Interfaces |
USB, Wi-Fi, Ethernet |
File formats supported |
.stl, .obj |
Cameras |
|
Thread end detection sensor |
|
Work Desk |
|
Length of printing area |
305 mm |
Wideness of the printing area |
305 mm |
Height of the printing area |
406 mm |
Table material |
Ceramics |
Warm the table |
|
Temperature of the table |
160 °C |
Automated platform calibration |
|
Components |
|
Nozzle |
0.4 mm |
Requires assemblies |
|
Dimensions and weight |
|
Length |
720 mm |
Width |
680 mm |
Heights |
1 470 mm |
Weight (disambiguation) |
220 kg |
