Printing Technology: FDM, Accuracy on the X-axis, Y: 1.25 microns, Z axis accuracy: 1.25 microns Materials: PLA, ABS, HIPS, PVA, FLEX, Nylon, PP, PETG, min. layer thickness: 50 microns Desktop: 300 x 400 mm, table material: glass, heating the table Design: extruders: 2, Extruder temperature: 280 degC
General Characteristics |
|
Printing Technology |
FDM |
Number of extruders |
2 |
Corpus |
closed-ended |
Frame material |
steel |
Min. layer thickness |
50 microns |
Printable material |
PLA, ABS, HIPS, PVA, FLEX, Nylon, PP, PETG |
Material Thickness |
1.75 mm |
Colors |
black |
Technical Specifications |
|
Positioning accuracy of the axis X, Y |
1.25 microns |
Positioning accuracy of the axis Z |
1.25 microns |
Extruder temperature |
280 °C |
Max. printing speed |
100 mm/s |
Color Prints |
|
Displays |
|
MANAGEMENT |
joystick |
Interfaces |
USB |
Cameras |
|
Control of residual plasticity |
|
Thread end detection sensor |
|
Work Desk |
|
Length of printing area |
300 mm |
Wideness of the printing area |
300 mm |
Height of the printing area |
400 mm |
Table material |
Glass |
Warm the table |
|
Temperature of the table |
125 °C |
Automated platform calibration |
|
Components |
|
Memory Cards |
|
Nozzle |
.3, 0.5 mm |
Requires assemblies |
|
Dimensions and weight |
|
Length |
563 mm |
Width |
525 mm |
Heights |
849 mm |
