Printing Technology: FDM, Accuracy on the X-axis, Y: 1.5 microns, Z axis accuracy: 1.25 microns Materials: PLA, PETG, min. layer thickness: 90 microns Desktop: 135x130 mm, heating the table Design: extruders: 2, Extruder temperature: 380 degC
General Characteristics |
|
Printing Technology |
FDM |
Number of extruders |
2 |
Corpus |
closed-ended |
Frame material |
Aluminium |
Min. layer thickness |
90 microns |
Printable material |
PLA, PETG |
Material Thickness |
1.75 mm |
Power Utilized |
160 W |
Colors |
black |
Technical Specifications |
|
Positioning accuracy of the axis X, Y |
1.5 microns |
Positioning accuracy of the axis Z |
1.25 microns |
Extruder temperature |
380 °C |
Displays |
|
Interfaces |
microSD/SD card |
File formats supported |
.stl, .obj, .3mf, .dxf |
Work Desk |
|
Length of printing area |
135 mm |
Wideness of the printing area |
135 mm |
Height of the printing area |
130 mm |
Warm the table |
|
Temperature of the table |
90 °C |
Components |
|
Memory Cards |
|
Nozzle |
0.4 mm |
Requires assemblies |
|
Dimensions and weight |
|
Length |
350 mm |
Width |
350 mm |
Heights |
400 mm |
Weight (disambiguation) |
22.5 kg |
