Printing Technology: FDM, Accuracy on the X-axis, Y: 12.5 microns, Z axis accuracy: 2.5 microns Materials: PLA, ABS, HIPS, min. layer thickness: 100 microns Desktop: 230x240x300 mm, heating the table Design: extruders: 1, Extruder temperature: 260 degC
General Characteristics |
|
Printing Technology |
FDM |
Number of extruders |
1 |
Corpus |
open-ended |
Frame material |
Aluminium |
Min. layer thickness |
100 microns |
Printable material |
PLA, ABS, HIPS |
Material Thickness |
1.75 mm |
Colors |
black |
Technical Specifications |
|
Positioning accuracy of the axis X, Y |
12.5 microns |
Positioning accuracy of the axis Z |
2.5 microns |
Extruder temperature |
260 °C |
Max. printing speed |
60 mm/s |
Color Prints |
|
Displays |
|
MANAGEMENT |
Button |
Interfaces |
USB, microSD/SD card |
File formats supported |
.gcode, .stl, .amf, .obj |
Cameras |
|
Control of residual plasticity |
|
Work Desk |
|
Length of printing area |
230 mm |
Wideness of the printing area |
230 mm |
Height of the printing area |
300 mm |
Warm the table |
|
Temperature of the table |
100 °C |
Automated platform calibration |
|
Components |
|
Nozzle |
0.4 mm |
Requires assemblies |
|
Dimensions and weight |
|
Length |
380 mm |
Width |
380 mm |
Heights |
680 mm |
Weight (disambiguation) |
7 kg (disambiguation) |
