Printing Technology: FDM, Accuracy on the X-axis, Y: 2 microns, Z axis accuracy: 5 microns Materials: PLA, ABS, HIPS, PVA, FLEX, Nylon, PC, PET, PP, PETG, TPU, min. layer thickness: 10 microns Desktop: 200 x 300 mm, table material: glass, heating the table Design: extruders: 1, Extruder temperature: 300 degC
General Characteristics |
|
Printing Technology |
FDM |
Number of extruders |
1 |
Corpus |
closed-ended |
Frame material |
Aluminium |
Min. layer thickness |
10 micron |
Printable material |
PLA, ABS, HIPS, PVA, FLEX, Nylon, PC, PET, PP, PETG, TPU |
Material Thickness |
1.75 mm |
Power Utilized |
360 W |
Colors |
black |
Technical Specifications |
|
Positioning accuracy of the axis X, Y |
2 microns |
Positioning accuracy of the axis Z |
5 micron |
Extruder temperature |
300 °C |
Max. printing speed |
300 mm/s |
Displays |
|
MANAGEMENT |
touchscreen display |
Interfaces |
USB, Wi-Fi, Ethernet |
File formats supported |
.gcode, .stl, .obj |
Pauses in printing |
|
Work Desk |
|
Length of printing area |
200 mm |
Wideness of the printing area |
200 mm |
Height of the printing area |
200 mm |
Table material |
Glass |
Warm the table |
|
Temperature of the table |
120 °C |
Automated platform calibration |
|
Components |
|
Memory Cards |
|
Nozzle |
0.4 mm |
Requires assemblies |
|
Dimensions and weight |
|
Length |
381 mm |
Width |
340 mm |
Heights |
660 mm |
Weight (disambiguation) |
29.6 kg |
