Printing Technology: FDM, Accuracy on the X-axis, Y: 6.9 microns, Z axis accuracy: 2.5 microns Materials: PLA, ABS, FLEX, Nylon, PC, PP, TPU, min. layer thickness: 20 microns Desktop: 330x240x300 mm, table material: glass, heating the table Design: extruders: 2, Extruder temperature: 180 - 280 degC
General Characteristics |
|
Printing Technology |
FDM |
Number of extruders |
2 |
Corpus |
closed-ended |
Min. layer thickness |
20 microns |
Printable material |
PLA, ABS, FLEX, Nylon, PC, PP, TPU |
Material Thickness |
2.85 mm |
Power Utilized |
500 W |
Colors |
White |
Technical Specifications |
|
Positioning accuracy of the axis X, Y |
6.9 microns |
Positioning accuracy of the axis Z |
2.5 microns |
Extruder temperature |
180 — 280 °C |
Color Prints |
|
Displays |
|
MANAGEMENT |
touchscreen display |
Interfaces |
USB, Wi-Fi, Ethernet |
File formats supported |
.gcode, .stl, .obj, .3mf, .jpg |
Cameras |
|
Pauses in printing |
|
Thread end detection sensor |
|
Work Desk |
|
Length of printing area |
330 mm |
Wideness of the printing area |
240 mm |
Height of the printing area |
300 mm |
Table material |
Glass |
Warm the table |
|
Temperature of the table |
20 — 140 °C |
Automated platform calibration |
|
Components |
|
Memory Cards |
|
Nozzle |
0.4 mm |
Requires assemblies |
|
Dimensions and weight |
|
Length |
457 mm |
Width |
495 mm |
Heights |
520 mm |
Weight (disambiguation) |
20.6 kg |
