Printing Technology: FDM, Accuracy on the X-axis, Y: 100 microns, Z axis accuracy: 100 microns Materials: PLA, ABS, PETG, TPU, min. layer thickness: 100 microns Desktop: 175 x 165 mm, heating the table Design: extruders: 1, Extruder temperature: 250 degC
General Characteristics |
|
Printing Technology |
FDM |
Number of extruders |
1 |
Corpus |
closed-ended |
Min. layer thickness |
100 microns |
Printable material |
PLA, ABS, PETG, TPU |
Material Thickness |
1.75 mm |
Power Utilized |
150 W |
Colors |
white, grey |
Technical Specifications |
|
Positioning accuracy of the axis X, Y |
100 microns |
Positioning accuracy of the axis Z |
100 microns |
Extruder temperature |
250 °C |
Color Prints |
|
Displays |
|
MANAGEMENT |
touchscreen display, mobile app |
Interfaces |
USB, microSD/SD card, Wi-Fi |
File formats supported |
.stl, .obj |
Cameras |
|
Pauses in printing |
|
Thread end detection sensor |
|
Work Desk |
|
Length of printing area |
175 mm |
Wideness of the printing area |
175 mm |
Height of the printing area |
165 mm |
Warm the table |
|
Temperature of the table |
80 °C |
Automated platform calibration |
|
Components |
|
Nozzle |
0.4 mm |
Requires assemblies |
|
Dimensions and weight |
|
Length |
400 mm |
Width |
380 mm |
Heights |
430 mm |
Weight (disambiguation) |
11.5 kg |
