Printing Technology: FDM, Accuracy on the X-axis, Y: 12.5 microns, Z axis accuracy: 10 microns Materials: PLA, ABS, HIPS, PVA, FLEX, PC, PP, PETG, TPU, SBS, ASA, Nylon (PA), min. layer thickness: 50 microns Desktop: 240 x 295 mm, table material: glass, heating the table Design: extruders: 1, Extruder temperature: 410 degC
General Characteristics |
|
Printing Technology |
FDM |
Number of extruders |
1 |
Corpus |
closed-ended |
Frame material |
steel |
Min. layer thickness |
50 microns |
Printable material |
PLA, ABS, HIPS, PVA, FLEX, PC, PP, PETG, TPU, SBS, ASA, Nylon (PA) |
Material Thickness |
1.75 mm |
Power Utilized |
350 W |
Colors |
black, white |
Technical Specifications |
|
Positioning accuracy of the axis X, Y |
12.5 microns |
Positioning accuracy of the axis Z |
10 micron |
Extruder temperature |
410 °C |
Max. printing speed |
150 mm/s |
Color Prints |
|
Displays |
|
MANAGEMENT |
joystick |
Interfaces |
USB, microSD/SD card, Wi-Fi |
File formats supported |
.stl, .obj |
Cameras |
|
Thread end detection sensor |
|
Work Desk |
|
Length of printing area |
240 mm |
Wideness of the printing area |
240 mm |
Height of the printing area |
295 mm |
Table material |
Glass |
Warm the table |
|
Automated platform calibration |
|
Components |
|
Memory Cards |
|
Nozzle |
0.4 mm |
Requires assemblies |
|
