Printing Technology: FDM, Accuracy on the X-axis, Y: 5 microns, Z axis accuracy: 5 microns Materials: PLA, ABS, FLEX, Nylon, PETG, min. layer thickness: 150 microns Desktop: 120x130 x140 mm, heating the table Design: extruders: 1, Extruder temperature: 299 degC
General Characteristics |
|
Printing Technology |
FDM |
Number of extruders |
1 |
Corpus |
closed-ended |
Frame material |
steel |
Min. layer thickness |
150 microns |
Printable material |
PLA, ABS, FLEX, Nylon, PETG |
Material Thickness |
1.75 mm |
Power Utilized |
90 W |
Colors |
black, white |
Technical Specifications |
|
Positioning accuracy of the axis X, Y |
5 micron |
Positioning accuracy of the axis Z |
5 micron |
Extruder temperature |
299 °C |
Max. printing speed |
200 mm/s |
Color Prints |
|
Displays |
|
MANAGEMENT |
touchscreen display |
Interfaces |
USB, Wi-Fi, Ethernet |
File formats supported |
.stl, .obj, .3mf, .ply |
Cameras |
|
Pauses in printing |
|
Work Desk |
|
Length of printing area |
120 mm |
Wideness of the printing area |
120 mm |
Height of the printing area |
120 mm |
Warm the table |
|
Temperature of the table |
70 °C |
Automated platform calibration |
|
Components |
|
Memory Cards |
|
Nozzle |
0.4 mm |
Requires assemblies |
|
Dimensions and weight |
|
Length |
255 mm |
Width |
365 mm |
Heights |
385 mm |
Weight (disambiguation) |
7.5 kg |
