Printing Technology: FDM, Accuracy on the X-axis, Y: 40 microns, Z axis accuracy: 10 microns Materials: PLA, ABS, HIPS, PVA, FLEX, Nylon, min. layer thickness: 15 microns Desktop: 190x215x230 mm, table material: glass, heating the table Design: extruders: 2
General Characteristics |
|
Printing Technology |
FDM |
Number of extruders |
2 |
Corpus |
closed-ended |
Frame material |
steel |
Min. layer thickness |
15 microns |
Printable material |
PLA, ABS, HIPS, PVA, FLEX, Nylon |
Material Thickness |
1.75 mm |
Colors |
black |
Technical Specifications |
|
Positioning accuracy of the axis X, Y |
40 microns |
Positioning accuracy of the axis Z |
10 micron |
Color Prints |
|
Displays |
|
MANAGEMENT |
joystick |
Interfaces |
USB |
Cameras |
|
Pauses in printing |
|
Control of residual plasticity |
|
Work Desk |
|
Length of printing area |
190 mm |
Wideness of the printing area |
215 mm |
Height of the printing area |
230 mm |
Table material |
Glass |
Warm the table |
|
Automated platform calibration |
|
Components |
|
Memory Cards |
|
Nozzle |
0.3 mm |
Requires assemblies |
|
Dimensions and weight |
|
Length |
460 mm |
Width |
360 mm |
Heights |
370 mm |
Weight (disambiguation) |
20 kg (disambiguation) |
